Power supply |
400 | 50 | 3 |
Volt|Hz|Phase |
Motor power |
1,9 - 1,1 ( 2,5 - 1,5 ) |
kW ( hp ) |
Motor speed |
2800 - 1400 |
rpm |
Acoustic emission |
70 |
dB |
Overall dimension (Width x Depth x Height) |
900 x 600 x H. 1850 |
mm |
Weight standard machine |
150 |
kg |
Abrasive belt dimension (wide x length) |
50 x 2000 ÷ 2500 |
mm |
Peripheral speed |
30 - 15 |
m/sec |
Dimensions of grooved rubberized driving wheel (wide x diameter) |
50 x ø 200 |
mm |
Orientable belt grinding arm |
0 ÷ 90 |
° |
Abrasive disc dimension |
ø 400 |
mm |
Peripheral speed |
60 - 30 |
m/sec |
Support table dimension |
450 x 230 |
mm |
Support table revolution |
0 ÷ 90 |
° |
